Спецификација
Wireless
Standards
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Signal Rate
Up to 300Mbps
Frequency Range
2.4-2.4835GHz
Transmit Power
20dBm(MAX)
Data Transfer Rate
802.11n:
40MHz (300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps)
20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense)
801.11g:
(54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps)
802.11b:
(11Mbps, 9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Wireless Mode
AP, Repeater, AP+WDS, WDS, Client, Multi-SSID
Wireless Security
64/128-bit WEP,
WPA-PSK/WPA2-PSK (TKIP/AES)
SSID Broadcast Enable/Disable
Wireless MAC Filtering
Hardware
Standards
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
Interface
1 * 10/100Mbps Auto MDI/MDIX RJ45 WAN port
2 * 10/100Mbps Auto MDI/MDIX RJ45 LAN port
LED
PWR, WLAN, LAN1-LAN4, WAN, WPS
Button
WPS, Default
Antenna
2* 5dBi Fixed Antenna
Power Supply
DC 9V/500mA (Output)
Software
WAN Type
DHCP, Static IP, PPPoE, L2TP, PPTP, Dual Access, WISP
Port Forwarding
Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port
QoS
WMM, Bandwidth Control
Access Control
IP/MAC/Domain Filtering
VPN Pass-through
PPTP, L2TP, IPSec
Others
IPTV, Dynamic DNS, Static Routing, WOL, Backup & Restore, Firmware Upgrade
Others
Certification
FCC, CE
Environment
Operating Temperature: 0?~40?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Package
1* W1
1* 9V/500mA Power Adapter
1* Quick Installation Guide (Multilingual)
